All type E coupler are furnished with bodies ,knuckled and locks of quenched and tempered grade E steel . Grade E material is identified by the letter E at the end of the item Catalog Number or ID Number.

The Type E operating parts are designed so that they will not fit into other types of couplers, except as listed:

C10 Knuckle Pin: used in all AAR coupler types

C2 Retainer Pin: used in all AAR couplers with inverted knuckle pins

E6A Top lock lift assembly : used in all top operating couplers

E TYPE COUPLER PART LIST:

E60E  ,SBE60EE SE60EE E67DE SBE67DE SE67DE

Type E Couplers and parts are regulated by the following AAR Specifications and Interchange Rules:

Ø  M-118 Knuckle Pins & Shank Connecting Pins

Ø  M-201 General for Steel Castings

Ø  S-172 Inspection & Maintenance on Cars

Ø  M-211 Purchase & Acceptance

Ø  M-212 Secondhand & Reconditioned

Ø  Rule 16 Type E Couplers & Parts

Ø  Rule 17 E/F Couplers & Parts

Ø  Rule 18 Type F Couplers & Parts

Ø  Rule 19 Yokes for Type E Couplers

Ø  Rule 20 Yokes for Type F and E/F Couplers

Ø  Rule 21 Front Follower Blocks

Ø  Rule 88 Couplers & Parts Required for Car Acceptance

Ø  Rule 90 Couplers & Parts Prohibited in Interchange
